All-in-One 522kWh for Peak Shaving, Backup Power & Microgrid Applications
The SolarEast 522kWh liquid-cooled energy storage cabinet delivers enterprise-grade power resilience for commercial buildings, industrial facilities, and microgrid systems. Engineered with all-in-one integration — battery, PCS, EMS, BMS, thermal management, and fire protection in one compact outdoor enclosure — it enables intelligent peak shaving, seamless backup power, and scalable clean energy management.
Built for the world's most demanding energy environments. Certified for the world's most demanding markets.
✔ Advanced Liquid Cooling — 20% Longer Lifespan
✔ Smart Peak Shaving & Demand Response
✔ Modular Design — Expandable to 2MWh+
UN38.3
522kWh Commercial & Industrial All-in-One Energy Storage Cabinet
Overview
The SolarEast 522kWh C&I Energy Storage System Cabinet is a next-generation, high-density battery energy storage solution designed specifically for large commercial buildings, industrial manufacturing facilities, logistics parks, data centers, and utility-edge microgrids. As businesses face rising electricity tariffs, grid instability, and increasing sustainability mandates, the 522kWh ESS cabinet delivers a turnkey answer: intelligent energy dispatch, significant demand charge reduction, and guaranteed power continuity — all in a single weatherproof outdoor enclosure.
Engineered on the proven SolarEast all-in-one platform, this cabinet deeply integrates every critical subsystem: Grade A LiFePO4 battery cells, an intelligent Battery Management System (BMS), a Power Conversion System (PCS), an Energy Management System (EMS), advanced liquid cooling, a four-level fire protection system, and an AI-powered early warning module. The result is a system that is faster to install, easier to operate, and safer to run than multi-component alternatives.
System Architecture & Key Specifications
The 522kWh cabinet is built around high-capacity LiFePO4 prismatic cells sourced from top-tier suppliers including EVE, REPT BATTERO, and Hithium — all 100% brand-new Grade A cells with original factory QR codes. The liquid cooling architecture maintains optimal cell temperature across all operating conditions, extending cycle life beyond 8,000 cycles (>10 years service life) and outperforming conventional air-cooled cabinets by up to 20% in longevity.
The integrated PCS supports both grid-tied (on-grid) and off-grid operating modes, enabling flexible deployment across diverse project types — from grid-connected commercial rooftop solar + storage systems to fully independent industrial microgrids in remote locations.
The onboard EMS provides real-time energy monitoring, automated peak shaving scheduling, demand response optimization, and remote cloud-based management via standard communication protocols (RS485, CAN, Modbus, 4G/Ethernet).
Safety by Design
Safety is architected into every layer of the 522kWh cabinet:
- Cell Level: High-safety LiFePO4 chemistry with built-in thermal stability
- BMS Level: Multi-layer electrical protection with millisecond-speed fault cutoff
- Thermal Level: Precision liquid cooling prevents thermal runaway propagation
- System Level: AI-driven early warning detects abnormal conditions before they escalate
- Cabinet Level: Integrated fire detection, suppression, and leakage containment system
This four-level safety architecture meets the requirements of UL9540, UL1973, IEC 62619, NFPA 855, CE, and CB international certification standards, ensuring project bankability in North America, Europe, Australia, and beyond.
Modular & Scalable
The 522kWh cabinet is designed for parallel operation, allowing multiple units to be combined for total system capacities from 522kWh to 2MWh+ — all within a compact outdoor footprint. This building-block modularity eliminates the need for costly system redesigns as energy demand grows, making the 522kWh cabinet the right long-term investment for expanding industrial facilities and commercial campuses.
Rapid Deployment
With a plug-and-play all-in-one design, the 522kWh cabinet minimizes on-site installation time and commissioning complexity. Pre-integrated systems reduce labor costs and project risk compared to component-by-component assembly, enabling faster time-to-revenue for EPC contractors and project developers.
Inverter Compatibility
The 522kWh ESS is compatible with leading global inverter brands including Goodwe, Deye, Growatt, Sofar, Solis, and Megarevo, ensuring seamless integration into existing solar and hybrid power infrastructure.
Global Supply & Support
SolarEast supports wholesale, OEM, and ODM orders with delivery timelines of 7–14 days for samples and 35–60 days for mass production. With 22GWh annual production capacity across five manufacturing bases in China, SolarEast delivers consistent quality at scale. Our technical and after-sales team supports projects in over 100 countries.
High-Density 522kWh Liquid-Cooled Storage
Powered by 100% Grade A LiFePO4 prismatic cells (280Ah/314Ah) from EVE, REPT BATTERO, and Hithium, the 522kWh cabinet delivers exceptional energy density in a compact outdoor enclosure. The advanced liquid cooling system maintains precise cell temperature control, extending service life beyond 10 years and 8,000+ charge-discharge cycles — outperforming air-cooled alternatives by up to 20%.
All-in-One Integrated Architecture
Every critical component — LiFePO4 battery pack, PCS, EMS, BMS, liquid cooling, fire suppression, and AI early warning — is factory-integrated into a single IP55-rated weatherproof cabinet. This all-in-one design dramatically reduces installation time, eliminates integration risks, and lowers total project cost for EPC contractors, system integrators, and end-users alike.
Intelligent Peak Shaving & Demand Response
The built-in EMS continuously optimizes charge and discharge scheduling based on real-time electricity tariff data and facility load profiles. By automatically shifting energy consumption from peak to off-peak periods, the 522kWh ESS delivers measurable reductions in demand charges and electricity costs — with a typical ROI payback period of 3–6 years depending on local utility rates.
Four-Level Safety Protection System
Safety is non-negotiable. The 522kWh cabinet features a four-level protection architecture: AI-powered cell-level early warning, millisecond-speed multi-layer electrical fault cutoff, precision liquid cooling to prevent thermal runaway, and a comprehensive fire detection, suppression, and leakage containment system. Fully compliant with UL9540, UL1973, IEC 62619, NFPA 855, CE, and CB standards for global project deployment.
Modular Scalability to 2MWh+
The 522kWh cabinet supports parallel operation with multiple units, enabling seamless capacity expansion to 1MWh, 1.5MWh, 2MWh, or beyond — without system redesign. This building-block modularity future-proofs your energy infrastructure investment, accommodating business growth, additional renewable generation capacity, or evolving grid interconnection requirements.
Global Certification & On-Grid / Off-Grid Flexibility
Supporting both grid-tied and off-grid operating modes, the 522kWh ESS adapts to diverse deployment scenarios — from urban commercial rooftop solar+storage to remote industrial microgrids. With internationally recognized certifications (UL9540, IEC 62619, CE, CB, CEI-021) and compatibility with major global inverter brands (Goodwe, Deye, Growatt, Sofar, Solis), it is engineered for seamless deployment across North America, Europe, Asia-Pacific, and the Middle East.
Battery Side
| Cell Specification: LFP 3.2V/314Ah |
| Battery RACK Configuration: 1P220S |
| System Capacity: 221.05kWh |
| Voltage Range: 594~792V |
| Nominal Voltage: 704V |
| Cycle Life: 8000Cycles(0.5P,25+2°C,@70%SOH) |
Ac grid connection side
| Rated Power: 100kW |
Way of Connection: 3P+N+PE |
| Allowable Grid Frequency Range: 50/60H(45-55Hz/55-65Hz) |
Ac off-network side
| Allowable Grid Voltage Range: 380V/400V |
| Way of Connection: 3P+N+PE |
| Allowable Grid Frequency Range: 50/60 |
| Off-grid switching time: ＜20ms |
System Parameter
| System Efficiency: ＞86% |
| Environmental Temperature: －20-55℃ |
| Humidity: ≤95% |
| Cooling method: Air cooling |
| Maximum working altitude: 2000m |
| Fire safety configuration: Aerosol |
| Communication Interface: Ethernet/CAN/RS485 |
| Compliant with standards: GB/T 34120，GB/T 36276， |
Application Scenarios for the 522kWh C&I Energy Storage Cabinet
The SolarEast 522kWh liquid-cooled energy storage cabinet is engineered for high-demand commercial and industrial environments where power reliability, cost efficiency, and energy independence are business-critical priorities.
① Industrial Manufacturing Facilities Factories and manufacturing plants face significant exposure to demand charge spikes during production peaks. The 522kWh ESS automatically dispatches stored energy during peak demand windows, reducing maximum demand charges, stabilizing power supply quality, and protecting sensitive production equipment from voltage fluctuations and grid disturbances.
② Commercial Buildings & Business Parks Office towers, shopping malls, logistics centers, and mixed-use commercial complexes can leverage the 522kWh cabinet for peak shaving, backup power during grid outages, and integration with rooftop or carport solar PV systems — reducing operational energy costs while improving ESG reporting metrics and building energy ratings.
③ Industrial Parks & Economic Development Zones Large industrial parks with multiple tenants benefit from centralized 522kWh BESS deployments that optimize shared energy procurement, enable demand response participation, and support on-site renewable energy integration as part of green industrial zone certification programs.
④ Microgrids & Off-Grid Industrial Sites Remote mining operations, oil & gas facilities, island communities, and off-grid industrial sites can deploy the 522kWh cabinet as the primary energy storage backbone of an independent microgrid — paired with solar PV, wind, or diesel generation — to deliver reliable, cost-effective power without dependence on centralized grid infrastructure.
⑤ Data Centers & Critical Infrastructure For mission-critical facilities where power interruption is unacceptable, the 522kWh ESS provides high-capacity uninterruptible backup power, seamlessly transitioning to battery supply within milliseconds of a grid fault, ensuring continuous operations and protecting against data loss or equipment damage.
⑥ C&I Solar + Storage Projects The 522kWh cabinet is the ideal energy storage partner for large commercial and industrial solar PV installations — maximizing self-consumption of generated solar energy, enabling energy arbitrage, and supporting grid export management to optimize returns on solar investment under net metering or feed-in tariff regimes.
Limited-Time Business Offer: Bigger Orders = Bigger Rewards!
Solve the problem of staggered peaks, improve power quality and be prepared for any problems
Upgrade Your Energy Storage System & Unlock Exclusive Perks
If you are looking for 100kWh to 522kWh Energy Storage Cabinet System and want to know more about the technical information, please feel free to contact SolarEast BESS.
Our Factory
SolarEast BESS is committed to delivering quality industrial and large scale ESS facilities professional technicasupport and thoughtful customer services beyond your expectations.
Our innovative solar and lithium battery solutions have reached clients in over 100 countries, empowering homes and businesses with sustainable, reliable energy.
SolarEast business scope covers the global market. It has formed strategic partnerships with many famous brands worldwide, and has exported to more than 100 countries, including the United States, Canada, the United Kingdom, Germany, Australia, the Philippines, Lebanon, etc. SolarEast energy storage has passed the global mainstream certification, in line with the North American UL9540, UL1973, European CB/CE, and Italian CEI-021 standards.
With SolarEast, you can benefit from:
One-Stop Service
Full support from needs assessment and system design to installation and maintenance
Efficient Storage Solutions
Lower energy costs and enhance energy utilization
Smart Management
Enable peak shaving, load shifting, and backup power functionalities
Renewable Integration
Seamlessly integrate solar, wind, and other renewable energy sources for a sustainable future
