Scalable Design
Supports seamless parallel connections via CTP technology, enabling easy system expansion.
Long Cycle Life
Over 8000 cycles at 70% SOH, ensuring more than 15 years of reliable performance under typical use.
Advanced Safety
Equipped with an aerosol fire safety system, meeting strict protection standards.
Wide Operating Range
Works efficiently in extreme environments, with a temperature range of -30°C to 50°C and up to 3000m altitude.
Certified with IP20 protection for safe indoor use.
314Ah LFP
Specifications
| Model | SE-BP-314L-1P16S | |
| Cell Capacity&Type | 314Ah LFP | |
| Group configuration | 1P16S | |
| Nominal capacity | 16.076kWh(@25°C±2) | |
| Efficiency | ≥94% | |
| Max. constant charging/discharging power | 0.5P | |
| Range of operating voltage | 43.2~57.6V | |
| Max. range of working temperature | Charging: 0℃~55℃ Discharging: -30℃~55℃ | |
| IP rating | IP20 | |
| Cooling method | Air cooling | |
| Weight | 120kg | |
| Dimension(W*D*H) | 483mm×814mm×235mm | |
| Fire safety configuration | Aerosol | |
| Cycle Life | 8000 |
SolarEast BESS is committed to delivering quality industrial and large scale ESS facilities professional technicasupport and thoughtful customer services beyond your expectations.
SolarEast business scope covers the global market. It has formed strategic partnerships with many famous brands worldwide.
With SolarEast, you can benefit from:
One-Stop Service
Efficient Storage Solutions
Smart Management
Renewable Integration
FREE Request a Quote! Fill out the form to connect with us!
