Professional Battery Energy Storage Systems Manufacturer
We utilize EVE's safe and reliable LiFePO4 cells Additionally, we collaborate with other leading battery cell brands including REPT BATTERO and Hithium.
Delivery Time: 7-14 days for samples, 35-60days for mass production.
Certified and Trusted: Our product meets rigorous international standards including CE, RoHS, UN38.3, and MSDS certifications, affirming its quality and reliability.
Seamless Integration: Compatible with leading inverter brands including Goodwe, Deye, Growatt, and Sofar, ensuring a smooth and efficient setup with your existing solar power infrastructure.
UN38.3
Product Features and Advantages
IP67 Protection
Use lithium iron phosphate (LiFePO4) cells with high thermal stability. Thermal insulation material between battery cells, preventing heat diffusion at temperatures up to 1000°C. Fine-tuned fire safety design with internal fire suppression. IP67 high safety protection level.
Wide Operating Range
Functions in extreme environments with a temperature range of -30°C to 50°C and altitudes up to 3000m. Optimized flow channel design through thermal simulation ensures a temperature difference of less than 3°C within a single pack, ensuring cell stability and reliability.
Efficient Cooling
Modular design to match container and cabinet energy storage. Modular high energy density design for smaller size and lighter weight. Liquid-cooling system keeps temperature variance within ≤3°C for stable performance.
Long Cycle Life
Over 8000 cycles at 70% SOH, ensuring more than 15 years of reliable service. Supports parallel connections via CTP technology to meet growing energy needs.
Technical Specifications
314Ah LFP
Specifications
| Model | SE-BP-314L1P48S | ||
| Cell Capacity&Type | 314Ah LFP | ||
| Group configuration | 1P48S | ||
| Nominal capacity | 48.23kWh(@25°C±2) | ||
| Efficiency | ≥94% | ||
| Max. constant charging/discharging power | 0.5P | ||
| Range of operating voltage | 129.6~172.8V | ||
| Max. range of working temperature | Charging: 0℃~55℃ Discharging: -30℃~55℃ | ||
| IP rating | IP67 | ||
| Cooling method | Liquid cooling | ||
| Weight | 315kg | ||
| Dimension(W*D*H) | 790mm×1065mm×245mm | ||
| Fire safety configuration | Aerosol | ||
| Cycle Life | 8000 |
Product Application
Residential Solar+: 3-day backup for average households. For backup power and energy independence.
Commercial Peak Shaving: 30% demand charge reduction. Suitable for businesses and commercial applications that require reliable energy storage.
Telecom Towers: Off-grid operation up to 2-3 days
EV Charging Hubs: Buffer 10+ fast charges daily
Microgrid Nodes: Plug-and-play grid support. Its IP67 protection and wide temperature range make it ideal for both indoor and outdoor installations in diverse environments.
Our Factory
SolarEast BESS is committed to delivering quality industrial and large scale ESS facilities professional technicasupport and thoughtful customer services beyond your expectations.
If you are looking for Liquid-Cooled Energy Storage Battery Pack and want to know more about the technical information, please feel free to contact SolarEast BESS.
Customized Energy Storage Battery Pack
At SolarEast BESS, We offer a variety of customized solutions to meet the diverse needs of residential and commercial applications. Customization options include battery cells, protection levels, Battery Management System (BMS), and capacity. Details are as follows:
Battery Type: Choose battery chemistry based on factors such as cycle life, cost, and safety.
Capacity: Customize the capacity of the battery pack according to specific requirements.
Voltage: Select different nominal voltages based on system requirements and compatibility.
Cooling Method: Choose between air-cooled or liquid-cooled designs based on environmental conditions and cooling efficiency needs.
Protection Level: Customizable protection features, such as IP ratings (e.g., IP20, IP67), to ensure safe operation in both indoor and outdoor environments.
Battery Management System (BMS): Customize the Battery Management System (BMS) with features such as remote monitoring, advanced safety protocols, and real-time performance tracking.
ESS Battery Pack Package
SolarEast BESS typically uses two types of packaging: Cardboard Box Packaging and Wooden Box Packaging. However, we also offer alternative packaging options based on customer requirements, including:
Cardboard Box Packaging: Lightweight and cost-effective packaging for small ESS components, such as battery cells and controllers, often with protective materials like foam.
Wooden Box Packaging: Durable packaging for medium-sized or heavy ESS components, providing strong protection against impact and environmental factors.
Shockproof Packaging: Packaging with shock-absorbing materials, such as foam, to protect sensitive ESS components from vibrations and impacts during transport.
Containerized Packaging: Used for large, heavy ESS systems or components, placed in containers to prevent shifting and protect against environmental factors during transport.
Your One-Stop Energy Solution Provider
SolarEast is a trusted provider of comprehensive energy solutions. We're committed to providing prompt, professional support and delivering customized battery energy storage system solutions for industrial and commercial clients. Whether it’s energy management, cost optimization, or renewable energy integration, we offer professional expertise and tailored services to ensure your energy needs are always met with the highest level of service.
With SolarEast, you can benefit from:
One-Stop Service
Full support from needs assessment and system design to installation and maintenance
Efficient Storage Solutions
Lower energy costs and enhance energy utilization
Smart Management
Enable peak shaving, load shifting, and backup power functionalities
Renewable Integration
Seamlessly integrate solar, wind, and other renewable energy sources for a sustainable future
